Customized silk covered litz wire 0.025mm-0.5mm Stranded Copper Litz Wire for Transformer

Informacion basica
Lugar de origen: PORCELANA
Nombre de la marca: RVYUAN
Certificación: ISO9001/ISO14001 /UL/SGS
Número de modelo: USTC
Cantidad de orden mínima: 10 kg
Precio: negotiable
Detalles de empaquetado: Carrete con cartón
Tiempo de entrega: 2-15 días de trabajo
Condiciones de pago: T/ t/ paypal
Capacidad de la fuente: Satisface tu demanda
Información detallada
Diámetro: 0.071 mm Temperatura: 155
Certificación: IEC/NEMA/JIS/RoHS/ISO Conductor: Cobre
Hilos: 250 Voltaje de desglose: 1300
Aislamiento: Uw Nombre del producto: Cable litz cubierto de seda personalizado 0.025 mm-0.5.5 mm Cobre de cobre litz para transformador
Palabra clave: Cable litz cubierto de seda personalizado 0.025 mm-0.5.5 mm Cobre de cobre litz para transformador
Resaltar:

custom silk litz wire

,

stranded copper litz wire

,

transformer litz wire


Descripción de producto

Customized Silk Covered Litz Wire 0.025mm-0.5mm Stranded Copper Litz Wire for Transformer
Our company specializes in providing custom silk covered litz wire, with single wire sizes ranging from 0.025mm to 0.5mm. We offer a wide range of strand counts, from single-strand to 13,000 strands, ensuring that we can meet your specific needs. In addition to silk-covered litz wire, we also supply taped litz wire and flat taped litz wire. Our products are meticulously crafted to meet your system requirements, ensuring optimal performance and reliability. With a commitment to quality and customization, we work closely with our clients to deliver litz wire solutions that perfectly align with their applications. Trust us to provide the ideal litz wire tailored to your specifications.
Product Specifications
Attribute Value
Diameter 0.071mm
Temperature 155
Certification IEC/NEMA/JIS/RoHS/ISO
Conductor Copper
Strands 250
Breakdown voltage 1300
Insulation UEW
Technical Specifications
Item Technical requests Test value 1 Test value 2
Conductor Diameter (mm) 0.076-0.084 0.079 0.080
Single wire diameter (mm) 0.071±0.003 0.068 0.070
O.D. (mm) Max. 1.85 1.57 1.68
Resistance Ω/m (20℃) Max. 0.01196 0.01815 0.01812
Breakdown Voltage V 950 3100 3000
Pitch mm 29± 5
No. of strands 250
Explore the endless possibilities of our natural silk-covered litz wire and experience the extraordinary experience of working with a trusted industry leader. Contact us today to discuss your needs and let us create the perfect wire solution for your next project.
Customized silk covered litz wire 0.025mm-0.5mm Stranded Copper Litz Wire for Transformer 0
